stainless steel barb ball valve
1.Product Name :stainless steel mini ball valve barb to male
2.Pressure :1000psi /PN63
3.Material :Stainless steel 304/316/316L /brass
4.Reduce port
5.Investment casting
Products Features
1.Product Name :stainless steel mini ball valve barb to male
2.Pressure :1000psi /PN63
3.Material :Stainless steel 304/316/316L /brass
4.Reduce port
5.Investment casting
6.Size :1/8’’-1’’
7.Blow-out proof stem
8.Sanitary design
9.Thread standard :ASME B1.20.1, BS21.0,DIN2999/259, ISO228-1,JIS B 0203,ISO7/1
10Inspection Testing :API598 .EN12266
11.Thread type :NPT, G, BSPT,BSPP ,RC
12.Temperature range: 14 ~ 248°FF (-10 ~ 120°FC), EPDM
Products Description
| Product Name |
Stainless Steel Mini barb to male 1/4" Ball Valve |
|
Material |
SS304 or SS316L |
|
Size |
1/8"-1" |
|
Standard |
3A, DIN |
|
Operating |
Manual |
|
Connection Way |
Female, Female X Male |
|
Seal Material |
PTFE |
|
Packing Details |
Usually bubble pack for each mini ball valve within carton box, Plywood case is also available depends on the quantity and the way of transport. |
Product order size
|
Size |
A |
B |
C |
D |
E |
F |
G |
H |
J |
Q |
|
1/4’’-8 |
66 |
59 |
30 |
19 |
10 |
8 |
24 |
37 |
21 |
18 |
|
1/4’’-10 |
68 |
60 |
29.5 |
21.5 |
10 |
10 |
22.5 |
36 |
20 |
18 |
|
1/2’’-10 |
73 |
70 |
33.5 |
25 |
11.5 |
10 |
27 |
40 |
24 |
18 |
|
1/2’’-12 |
73 |
70 |
33 |
25 |
12 |
12 |
27 |
40 |
24 |
18 |
About this Item
Stainless steel Ball valves use a spherical disc to control the flow between pipes, tubes, or hoses. Flow is allowed when the hole that pierces the ball-shaped disc is in line with the inlet and outlet of the valve and is blocked when the ball is horizontally swiveled 91 degrees, so that the hole of the ball is perpendicular to the opening of the valve. Mini ball valves are primarily used in air, gas, liquid and for home brew kettle.
Packing Delivery
Packing Details:
1.Standard carton packing
2. inner plastic bag, outer 1.07 x 1.07 x 1.14 M wooden case
3.We can also customize the packaging according to your requirements
4.Delivery Details : Shipped in 15-30 days after payment depend on quantities
