Air Operated Double Diaphragm Pump
1.Wetted Body Material: Stainless Steel 316
2.Constructed of FDA Accepted Materials
3.Bolted Construction with all Stainless Steel Hardware
4.Center Air Chamber Material: Aluminum Alloy
5.Diaphragm material: Teflon (TFM), Polyethylene(UPE), Santoprene (STP)
Stainless steel Air Operated Double Diaphragm Pump
Products Features
1.Wetted Body Material: Stainless Steel 316
2.Constructed of FDA Accepted Materials
3.Bolted Construction with all Stainless Steel Hardware
4.Center Air Chamber Material: Aluminum Alloy
5.Diaphragm material: Teflon (TFM), Polyethylene(UPE), Santoprene (STP)
6.It is suitable for the transportation of glycol, alcohol, sodium hydroxide, nitric acid, carbonic acid, fruit acid, enzyme, caustic soda, ammonia, asphalt, and some acid & alkali liquid
Products Description
●Air operated double diaphragm pump is a positive displacement pump that uses two sets of flexible membranes to pump fluids and a series of check valves to ensure fluid can only travel in one direction through the chamber. Pump cycling will begin as air pressure is applied. Air-operated diaphragm pumps utilize a pressure differential in the air chambers to alternately create suction in the fluid chambers.
●Stainless steel air operated double diaphragm pump particularly designed to meet the requirements of the food, beverage, pharmaceutical and cosmetic industries. Lubrication free air distribution system, maintenance free ball check valve system and total visual inspection of the wetted parts are some of the major features for this pump series
Products Specification
| Product Name |
Air operated double diaphragm pump |
|
|
Model |
BFQ-50 |
|
|
Material |
Stainless steel 316 /304 |
|
|
Max working flow |
150gpm (568Lpm ) |
|
|
Fluid inlet/outlet size |
2in (F) |
|
|
Max suction height |
5.48m |
|
|
Air inlet size |
1/2 in |
|
|
Max.Particle diameter |
1/4in (6.4mm ) |
|
|
Max,air consumption |
45scfm |
TYPICAL APPLICATIONS
●Dairy products:Milk, cream, yogurt, cream cheese, melted cheese
●Grossery:Ketchup, mayonnaise, tomato products, mustard
●Beverages:Flavours, colouring, fruit juice
●Bakery:Dough, ingredients
●Brewery:Beer, flavours, colouring, wort
●Hygiene:Soap, toothpaste, schampoo
●Cosmetics:Cream, alcohol, perfume
Advantages:
●Handels a wide variety of fluids with high solids content
●Self priming
●Ability to run dry
●Explosion proof
●Pumping efficiency remains constant
●No mechanical seals, couplings, or motors
●Can not overheat
Actual product pictures show
