TS Aluminum Alloy Pump
An aluminum alloy pneumatic diaphragm pump is a type of industrial pump that uses compressed air to move a flexible diaphragm back and forth, which in turn creates suction and discharge actions to transfer liquids.
Products Description
TS aluminum alloy pump
An aluminum alloy pneumatic diaphragm pump is a type of industrial pump that uses compressed air to move a flexible diaphragm back and forth, which in turn creates suction and discharge actions to transfer liquids. These pumps are constructed using aluminum alloy materials, which provide durability and corrosion resistance. They are often used in applications where the handling of corrosive or abrasive fluids is required, such as in the chemical, pharmaceutical, and wastewater treatment industries. Aluminum alloy diaphragm pumps are known for their reliability and ability to handle a wide range of fluids
Technical parameters
|
Part Number |
TS-15 |
|
|
Product Name |
Aluminum alloy pump Pneumatic Diaphragm Pump |
|
|
Max flow rate |
133lpm/min |
|
|
Air inlet size |
1/4’’-18NPTF |
|
|
Air inlet size |
Rp1(1-11BSP) |
|
|
Fluid inlet/outlet size |
Rp1(1-11BSP) |
|
|
Max working pressure |
120psi(8.3bar) |
|
|
Max pertniffed grain |
3.2mm |
|
|
Max.suction height |
6.1m |
More size for choosing
|
Part Number |
TS-40 |
|
|
Product Name |
Aluminum alloy pump Pneumatic Diaphragm Pump |
|
|
Max flow rate |
340.7lpm/min |
|
|
Air inlet size |
1/2’’-14NPTF |
|
|
Air inlet size |
Rp1-1/2(1-1/2’’-11BSP) |
|
|
Fluid inlet/outlet size |
Rp1-1/2’’(1-1/2’’-11BSP) |
|
|
Max working pressure |
120psi(8.3bar) |
|
|
Max pertniffed grain |
6.4mm |
|
|
Max.suction height |
5.8m |
|
Part Number |
TS-50 |
|
|
Product Name |
Aluminum alloy pump Pneumatic Diaphragm Pump |
|
|
Max flow rate |
651lpm/min |
|
|
Air inlet size |
3/4-14NPTF |
|
|
Air inlet size |
Rp2(2’’-11BSP) |
|
|
Fluid inlet/outlet size |
Rp2’’(2’’-11BSP) |
|
|
Max working pressure |
120psi(8.3bar) |
|
|
Max pertniffed grain |
6.4mm |
|
|
Max.suction height |
8.3m |
|
Part Number |
TS-80 |
|
|
Product Name |
Aluminum alloy pump Pneumatic Diaphragm Pump |
|
|
Max flow rate |
897lpm/min |
|
|
Air inlet size |
3/4-14NPTF |
|
|
Air inlet size |
Rp3(3’’-11BSP) |
|
|
Fluid inlet/outlet size |
Rp3’’(3’’-11BSP) |
|
|
Max working pressure |
120psi(8.3bar) |
|
|
Max pertniffed grain |
9.5mm |
|
|
Max.suction height |
5.4m |
Aluminum alloy diaphragm pump application
- Chemical transfer
- Paints and coating
- Food and beverage
- Pharmaceutical
- Waste water treatment
- Mining and construction
- Oil and gas
- Agriculture
- Automotive
- Water treatment
The performance of aluminum alloy pneumatic diaphragm pump
Corrosion Resistance: Aluminum alloy pumps are resistant to corrosion, making them suitable for a wide range of applications, including handling corrosive fluids.
Lightweight: Aluminum is a lightweight material, which makes these pumps easy to transport and install.
Durable: Aluminum alloys are known for their durability and long service life, ensuring reliable performance over time.
Chemical Compatibility: These pumps can handle various chemicals, which makes them versatile for different industrial processes.
Low Maintenance: They often require minimal maintenance due to their robust construction.
Self-Priming: Pneumatic diaphragm pumps can be self-priming, meaning they can handle fluids with air or gas entrapped in them.
Adjustable Flow: The flow rate of these pumps can be easily adjusted by changing the air pressure, providing flexibility in applications.
Explosion-Proof: Pneumatic diaphragm pumps are often chosen for applications where explosion-proof equipment is required, as they don't have electric motors.
